Configuring The Nginx Proxy In An Elastic Beanstalk Linux Environment

Configuring the nginx proxy in an Elastic Beanstalk Linux environment

How to resolve the error “upstream sent too big header while reading response header from upstream” by extending the nginx config in Elastic Beanstalk.

Bad Gateways & Big Headers

I was recently using Elastic Beanstalk to set up a dev/test environment for a Blazor web app, running .NET 5 on Amazon Linux. Without authentication, the app was working fine. But when authentication (via Azure AD) was enabled, the site gave a “502 - Bad Gateway” error.

Elastic Beanstalk lets you easily look at the logs of the underlying EC2 instances, and I soon found the issue in the logs for the nginx proxy:

```upstream sent too big header while reading response header from upstream

Sure enough, the headers were rather large.

### You're gonna need a bigger buffer

Turns out it's [not unusual](https://andrewlock.net/fixing-nginx-upstream-sent-too-big-header-error-when-running-an-ingress-controller-in-kubernetes/) for nginx to choke on large headers, and the solution is to change the nginx configuration to increase the buffer size. All your `nginx.conf` file needs is something like the following:

proxy_buffers 8 16k; proxy_buffer_size 16k; large_client_header_buffers 4 32k;

### Extending the nginx configuration in Elastic Beanstalk

At the time of writing this is a single instance environment, so it would be pretty easy to SSH onto the EC2 instance and append the above to nginx.conf. Not a very satisfactory solution, however, it's much more desirable to have the necessary config extension baked into the app source, so that if Elastic Beanstalk creates a new instance, the nginx proxy will be properly configured from the get-go.

As documented [here](https://docs.aws.amazon.com/elasticbeanstalk/latest/dg/platforms-linux-extend.html), this is very achievable. Simply ensure that when your application is built, the bundle will contain a folder called `.platform/nginx/conf.d/` containing any .conf files that you wish to append to the default `nginx.conf`. Elastic Beanstalk will pick these up automatically and include them in `nginx.conf`.

If you don't want to extend the nginx config, but instead overwrite it with your own version, make your own `nginx.conf` file and include it in the `.platform/nginx/` folder of your app bundle.

### Using AWS CodeBuild

This application was being built by AWS CodeBuild, so I added a command to the `buildspec.yml` to copy a file called `proxy.conf` to the appropriate folder. `proxy.conf` just contains the above text which I wanted to add to the nginx config.

The snippet below shows that the app will be published to a folder imaginatively named publish, hence copying `proxy.conf` from the root of the working directory (which is a copy of the source repo) to the folder `publish/.platform/nginx/conf.d/`

```yaml
post_build:
  commands:
    - mkdir -p publish/.platform/nginx/conf.d/ && cp proxy.conf publish/.platform/nginx/conf.d/proxy.conf
    - dotnet publish -c Release -f net5.0 -r linux-x64 -o ./publish MySubFolder/MyApp.csproj

artifacts:
  files:
    - ./**/*
  base-directory: publish
